Flush Outlet Tee Polished Stainless Steel for 1.5" O.D. Tubing (40-735/1H)
A streamed look is achieved with the use of flush handrail fittings. Our component options ensure simple assembly and flexibility to accommodate any project. Our line of flush handrail fittings feature a 1” long sleeve for added and adhesive coverage.
Fittings are supplied with self-drilling/self tapping hardware.
Material:
- 304-Grade Pollished Stainless Steel
Wall Thickness:
- .050"
Dimensions:
- W: 3"
- L: 2-1/4"
Estimated Lead time: 3-5 business days before shipment.
Cross two perpendicular 1.5" OD handrail runs at a single point with this four-outlet flush "X" fitting — the part for a true four-way intersection where two runs meet and continue in all directions. Flush joints throughout. Five finishes: polished brass, 304 polished or satin stainless, and 316 polished or satin stainless.
Description
Some rail layouts don't just turn or branch — they cross. This four-outlet flush "X" fitting joins two perpendicular 1.5" OD handrail runs at a single four-way junction, with each of the four tubes sliding in for a flush joint. It's the fitting for gridded rail layouts: a mezzanine or catwalk grid, a network of walkways, a point where multiple runs converge and each has to continue through. The five finishes cover most settings: polished brass for a traditional rail, 304 stainless polished or satin for a modern interior, and 316 stainless polished or satin where salt or chlorine calls for corrosion resistance. Being a four-way fitting, it does more at one junction than an elbow or a "T," which is why it's the piece to reach for wherever two runs genuinely cross. Note the OD won't interchange with 1.67" or 2" tubing.
